Proton Beam Range Verification Using Ionoacoustics

The Bragg Peak location can be precisely steered by the initial kinetic energy of the particles. However, an imprecise knowledge of the traversed integral tissue stopping powers within the patient results in range uncertainties becoming most problematic with an organ at risk closely behind the target. The main chal-lenge in ionoacoustics is to obtain sufficient information from the weak signals to obtain the desired accuracy of 1 mm in determining the Bragg Peak position and bring it in relation to the lesion or organs at risk.

The invention optimizes the signal-to-noise ratio of the ionoacoustic information. This is achieved by optimizing the beam parameters beam current, pulse duration, pulse shape and repetition rate. Ideal pulses are obtained without further beam manipulation from synchro-cyclotrons but also beams from other accelerators may easily be pulsed as required for optimized acoustic signal generation. Additionally, a matched filter has been applied to the detected signal. By co-registering an ultrasound image from the same position as the ionoacoustic detector, systematic uncertainties in determining the Bragg Peak position relative to organ at risks or the lesion itself can be kept below 1 mm.
